EventHub Explorer Documentation

EventHub Explorer is a developer tool that allows you to interact with Azure Event Hubs, Azure Storage Queues and Azure Service Bus using a graphical user interface. It supports real Azure services, the eventhubs-emulator for Event Hubs, the Azurite for StorageQueue, and the Service Bus emulator for Service Bus.

Features

Sending Messages to Event Hubs

Override GUID, DateTime values in a message before sending
Ability to compress and encode a message before sending
Send a single message
Send a batch of messages
Send a batch of messages with a time delay between each message

Receiving Messages from Event Hubs

Format a message to JSON if it is a JSON string
Ability to decompress and decode a message after receiving
Receive messages without checkpoints (always fetch the newest messages, if is not yet received another consumer)
Receive messages with checkpoints (using external storage to track received message IDs)

Note: The application uses the $Default consumer group by default.

Sending Messages to Storage Queues

Override GUID, DateTime values in a message before sending
Ability to compress and encode a message before sending
Send a single message
Send a batch of messages
Send a batch of messages with a time delay between each message

Receiving Messages from Storage Queues

Format a message to JSON if it is a JSON string
Ability to decompress and decode a message after receiving

Sending Messages to Service Bus

Override GUID, DateTime values in a message before sending
Ability to compress and encode a message before sending
Send a single message
Send a batch of messages
Send a batch of messages with a time delay between each message
Supports both Queue and Topic entity types

Receiving Messages from Service Bus

Format a message to JSON if it is a JSON string
Ability to decompress and decode a message after receiving
Receive messages from a Queue or a Topic Subscription

Example Connection Strings

Event Hubs Emulator

The Event Hubs emulator uses a static connection string. The host value depends on how your application is deployed relative to the emulator.

Application running natively on the same local machine as the emulator:

Endpoint=sb://localhost;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Application on a different machine on the same local network (use the IPv4 address of the machine running the emulator):

Endpoint=sb://192.168.x.y;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Application container on the same Docker bridge network (use the emulator container alias, default is eventhubs-emulator):

Endpoint=sb://eventhubs-emulator;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Application container on a different Docker bridge network:

Endpoint=sb://host.docker.internal;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Real Azure Event Hubs

Namespace-level connection string (access to all event hubs in the namespace):

Endpoint=sb://<NamespaceName>.servicebus.windows.net/;SharedAccessKeyName=<KeyName>;SharedAccessKey=<KeyValue>

Event hub-level connection string (access to a specific event hub):

Endpoint=sb://<NamespaceName>.servicebus.windows.net/;SharedAccessKeyName=<KeyName>;SharedAccessKey=<KeyValue>;EntityPath=<EventHubName>

Azurite Blob Storage (Emulator)

The default well-known account for Azurite:

Account name: devstoreaccount1
Account key: Eby8vdM02xNOcqFlqUwJPLlmEtlCDXJ1OUzFT50uSRZ6IFsuFq2UVErCz4I6tq/K1SZFPTOtr/KBHBeksoGMGw==

Running locally (localhost):

DefaultEndpointsProtocol=http;AccountName=devstoreaccount1;AccountKey=Eby8vdM02xNOcqFlqUwJPLlmEtlCDXJ1OUzFT50uSRZ6IFsuFq2UVErCz4I6tq/K1SZFPTOtr/KBHBeksoGMGw==;BlobEndpoint=http://127.0.0.1:10000/devstoreaccount1;

Running as a Docker container on the same bridge network (use the Azurite container service name, e.g. azurite):

DefaultEndpointsProtocol=http;AccountName=devstoreaccount1;AccountKey=Eby8vdM02xNOcqFlqUwJPLlmEtlCDXJ1OUzFT50uSRZ6IFsuFq2UVErCz4I6tq/K1SZFPTOtr/KBHBeksoGMGw==;BlobEndpoint=http://azurite:10000/devstoreaccount1;

Shortcut (when running locally without Docker):

UseDevelopmentStorage=true

Azurite Storage Queue (Emulator)

Running locally (localhost):

DefaultEndpointsProtocol=http;AccountName=devstoreaccount1;AccountKey=Eby8vdM02xNOcqFlqUwJPLlmEtlCDXJ1OUzFT50uSRZ6IFsuFq2UVErCz4I6tq/K1SZFPTOtr/KBHBeksoGMGw==;QueueEndpoint=http://127.0.0.1:10001/devstoreaccount1;

Running as a Docker container on the same bridge network (use the Azurite container service name, e.g. azurite):

DefaultEndpointsProtocol=http;AccountName=devstoreaccount1;AccountKey=Eby8vdM02xNOcqFlqUwJPLlmEtlCDXJ1OUzFT50uSRZ6IFsuFq2UVErCz4I6tq/K1SZFPTOtr/KBHBeksoGMGw==;QueueEndpoint=http://azurite:10001/devstoreaccount1;

Real Azure Storage Queue

DefaultEndpointsProtocol=https;AccountName=<AccountName>;AccountKey=<AccountKey>;QueueEndpoint=https://<AccountName>.queue.core.windows.net;

Service Bus Emulator

The Service Bus emulator uses a static connection string. The host value depends on how your application is deployed relative to the emulator.

Application running natively on the same local machine as the emulator:

Endpoint=sb://localhost;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Application on a different machine on the same local network (use the IPv4 address of the machine running the emulator):

Endpoint=sb://192.168.x.y;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Application container on the same Docker bridge network (use the emulator container alias, default is servicebus-emulator):

Endpoint=sb://servicebus-emulator;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Application container on a different Docker bridge network:

Endpoint=sb://host.docker.internal;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Note: For management operations (creating/deleting entities via the Administration Client), append port 5300 to the connection string. Example for local machine:

Endpoint=sb://localhost:5300;SharedAccessKeyName=RootManageSharedAccessKey;SharedAccessKey=SAS_KEY_VALUE;UseDevelopmentEmulator=true;

Real Azure Service Bus

Namespace-level connection string:

Endpoint=sb://<NamespaceName>.servicebus.windows.net/;SharedAccessKeyName=<KeyName>;SharedAccessKey=<KeyValue>

Requirements

Docker
Azure Event Hubs*
Blob Storage*
Storage Queue*
Service Bus*

* — the service you want to use

Install options

Option 1: Clone solution from the repo, build and run the solution locally, open in browser http://localhost:5235/
Option 2: Pull and run docker image docker pull dvlaskin/eventhubexplorer, open in browser http://localhost:5235/

Example of a docker compose file

services:

  eventhubexplorer:
    image: dvlaskin/eventhubexplorer:latest
    container_name: eventhubexplorer
    ports:
      - "5235:8080"
    volumes:
      - data-volume:/app/Data
    networks:
      - docker-network

volumes:
  data-volume:

networks:
  docker-network:
    external: true

License

MIT
